C17500 Copper Sheet/Plate(CDA 175)

Product Specification: C17500 Copper Sheet/Plate (CDA 175)

Material Overview
C17500 Copper Sheet/Plate (CDA 175) is a high-strength, premium copper alloy widely used in industries such as electronics, aerospace, and automotive. This material is renowned for its excellent conductivity and corrosion resistance, making it suitable for applications that require high strength and superior electrical performance.

Chemical Composition

• Copper (Cu): Approximately 96.5%
• Beryllium (Be): 1.8% - 2.0%
• Other Elements: ≤ 0.5% (such as aluminum, iron, magnesium, etc.)

Physical Properties

• Density: 8.3 g/cm³
• Melting Point: 900°C - 940°C
• Electrical Conductivity: ≥ 40% IACS
• Thermal Conductivity: 120 W/m·K

Mechanical Properties

• Yield Strength: ≥ 340 MPa
• Tensile Strength: ≥ 570 MPa
• Elongation: ≥ 10%
• Hardness: 90 - 110 HRB

Size Specifications

• Thickness Range: 0.5 mm - 100 mm
• Width Range: 100 mm - 1500 mm
• Length: Customizable according to customer requirements

Surface Treatment

• Various surface treatments are available, such as mirror finish, brushed finish, and anodizing, to meet specific customer needs.

Applications

• Electronic components
• Aerospace equipment
• Automotive parts
• Electrical connectors
• Industrial equipment

Packaging and Shipping

• Packaged with moisture-proof and rust-proof materials to ensure product integrity during transportation.

Notes

• C17500 copper alloy should be processed with care to avoid overheating, in order to maintain its excellent physical properties.
